The plastic haier ring packing is a new kind of perforated packing which is molded by polypropylene injection molding. Later, this kind of packing was studied in China and haier ring packing was successfully developed.
● the unique shape of haier ring makes it not only has the advantages of large flux, low pressure, good corrosion resistance and impact resistance, but also has the advantages of non-nesting between fillers, small wall flow effect and even distribution of gas and liquid.
● this packing is suitable for gas absorption, cooling and gas purification processes. The plastic haier ring is a new type of perforated filler, with a unique structure, the common is polypropylene injection molding, its specific surface area and void ratio is large to help improve the performance of the product.
| name | Plastic haier ring | ||||
| material | PP,RPP,PE,PVC,CPVC,PVDF,etc. | ||||
| service life | >3 years | ||||
| size | Dry packing factor | ||||
| mm | aream2/m3 | Void | number | weight | m-1 |
| % | per/ m3 | Kg/m3 | |||
| 50 | 107 | 94 | 8000 | 50 | 128 |
| 76 | 75 | 95 | 3420 | 45 | 87 |
| 100 | 55 | 96 | 1850 | 48 | 62 |
perfor mance | High voidage, low pressure, low height of mass transfer unit, high flooding point, sufficient gas-liquid contact, small specific gravity, high mass transfer efficiency | ||||
advan tages | 1. The special structure makes it have large circulation, low pressure and good mechanical strength. | ||||
| 2. Strong corrosion resistance, large void ratio, energy saving and environmental protection, low cost, light specific gravity easy loading and unloading. | |||||
Appli cation field | Gas absorption, acid gas adsorption system, washing tower, fertilizer production. For gas absorption tower, acid gas adsorption system, fertilizer production. Plastic bulk packing with a temperature of 280 degrees Celsius, widely used in petroleum, chemical, chlor-alkali, gas, environmental protection and other industries in the packed tower. | ||||
Properties materials | PE | PP | RPP | PVC | CPVC | PVDF |
| density | 0.98 | 0.96 | 1.2 | 1.7 | 1.8 | 1.8 |
| Operating | 90 | ＞100 | ＞120 | ＞60 | ＞90 | ＞150 |
| Corrosion | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
| strength | ＞6.0 | ＞6.0 | ＞6.0 | ＞6.0 | ＞6.0 | ＞6.0 |
